Technical

Overall size:5050mm*1810mm*1500mm

Box size:2260mm*1840mm*610mm

Toolbox size:800mm*800mm*660mm

Tare Mass:950kg

ATM:2000kg



Chassis

Heavy duty off road galvanized chassis frame

Zinc-coated steel plate then baked enamel

Integrated drawbar and chassis, fully welded

100*50*4mmQ345 RHS,3000mmextended draw bar (excluding coupling) for easy corner turning and better stopping

Dual (not single) drawbar safety chains

10'' heavy duty solid jockey wheel

Four heavy duty lockable and adjustable drop-down stabilizer legs

16’ ’ alloy 6-stud Land Cruiser pattern rims and LT265/75R16 off road tyres, including spare

Spare tyre in the tyre rack at the back of the trailer

One self-braked winch used for tent open and close with 1200N capacity

Gas Struts on both sides to help lifting tent



Suspension

Independent suspension with dual shock absorbers (each side), trailing arms and coil springs

12" electric drum brake system and manual stainless steel cable brake



Kitchen

Deluxe slide out stainless steel kitchen

Stainless steel sink with top quality tap

105L stainless steel water tank with electrical water pump and a tap attached to water tank (one extra water tank is optional if needed)

Lockable stainless steel water filler

2 x jerry can holder and 2 x gas bottle holder at each side

More storage: huge front fridge, generator box and extra drawers; more interior cupboards



Electric circuit

2x100A/H deep cycle battery

Anderson plug for battery charging from the tow vehicle

7 pin round plug for electric brake and direction lights

12V water pump to pump water to kitchen tap

Internal LED stripes with dual switches

Cigarette sockets

Additional LED kitchen light

Modern design LED tail lights

LED number plate light

Overload protection

Water sensor

Voltage meter (DC & AC)

1000w inverter

Solar power control panel (not including solar power board)



Internal

One king size bed with high quality mattress cushion

Large slide out drawer under the king bed

One living room with wooden floor



Tent

14OZ canvas, double stitched and extra water proof

Midge mesh screens and windows, tropical roof

Fully enclosed annex room with awning and side walls

Galvanized awning poles, pegs and ropes

Tent color is Grey but may vary from what you see from computers. Visit us to confirm.



Optional:

1.       Refrigerator

2.       Backup battery

3.       Generator

4.       Solar power system

5.       Larger inverter 6.  One more water tank with water pump 7.  Washroom with portable toilet and shower head 8.  Extra awning on the other side

9.       Boat rack 10.  Hand pump
